Fireroad CLASSIFIED
We measure performance across all metrics
25mm rim - 40mm Aero - 150MSEC SHIFTING- 180kg (400lb) System weight tested
Daphne Melverde Gravel bike
Takes you on the fire roads and beyond
The Lavelle Fireroad an elegant aerodynamic wheel which fits your gravel bike. Wide, super strong rims allows wider tyres. The Fireroad is supplied with our CLASSIFIED Powershift and ultra low friction bearings. This allows to remove the front derraullier and improve system efficiency for a wide range.
Jaegher Tom Bonnen Gravel bike
CLASSIFIED Powershift
The Fireroad CLASSIFIED adds the shifting integration to improve even more the capacity of the system to perform in challenging routes. Cleverly designed labyrinth seals offer water and grime protection.
Crafted carbon
Design optimised for a balance of stiffness, vibration absortion, weight and comfort.The carbon Fireroad wheel and tooling is all designed by our in-house team.
Each wheel is individually hand crafted using top of the range carbon fibre materials. This obsessive attention to detail results in a wheel which is super focused and lightening fast.
Aero
Featuring Concept-TW, our tyre/wheel design allows for wider tyres without any aero penalty by reducing the turbulence zone at the junction of the tyre and rim, saving watts where it matters most, the front-end of the bike.
Rim wall
An extra stiff thick wall rim was integrated, a detail overlooked by most manufacturers.
This feature increases dramatically the impact protection and reduces the tire sidewall puncture.
The wide rim allows wider tyres and provides major aero gains.
The technical design of the carbon does not mean we ignore the aesthetics.
The carbon placement results in a beautiful, symmetrical pattern and the resin we use is also UV protected without varnish.
Aesthetics
Bearings
We partnered with SKF to supply best in class bearings, selecting a configuration with 2,5x more efficiency than the standard steel 2RS.
Ceramic bearings were rejected as the hardened balls reduce efficiency over time and ceramic gains are not seen at such low rpms anyway.
The bearings are 2 times stronger than standard use bicycle bearings.
In house design and build
As a contribution to environmental sustainability we have developed an exceptionally low energy process that results in 1/6th of the energy consumption of industry standard carbon fibre manufacture.
We have developed a carbon manufacturing process that requires no harmful lacquers of varnishes.
Each wheel is hand built by our craftsman and individually signed off by quality control.
Using environmentally sustainable process
HIGH EFFICIENCY SYSTEM
GRAVEL FIT
INTEGRATED
POWERSHIFT
Faster shifting of the Industry standard
32MM RIM WIDTH
29 mm of the Industry standard
Carbon Manufacture
Carbon fibre strategically hand laid.
Herringbone lay pattern
One piece moulding
Carbon 1060 Grams set
Exceptionally low energy manufacturing process
Hubs
Front
Lavelle S250 Front hub 160 g
SKF 61903 X2
Rear Hub
CLASSIFIED Powershift rear hub compatible, not included in the set
All parts designed and built in-house
Geometry
29” 622X25 mm
25 mm inside rim 32 mm rim width
Sealed rim base
5 carbon spokes
Presta Valve Max Pressure 4 bar
Total weight 1400 grams
HubBody
Classified Powerhub
Brake disc
ISO 6 BOLTS
Crash Replacement Service
Not only do we offer a full two year manufacturer’s warranty, we also provide a crash replacement service.
Warranty
Year 1 - full manufacturer’s warranty
Year 2 - full manufacturer’s warranty
Crash replacement
Year 1 - 50% discount
Year 2 - 40% discount
Year 3 - 40% discount - Extendable premium service - see fee in store
* please see terms and conditions for details
